Read Range |
• ProID10 EM/IC 3.5cm • ProID20/30/40 EM/IC 5cm |
|
Reading Time |
• ≤300ms |
|
Input Port |
• External LED Control • External Buzzer Control |
|
Output Port |
• Wiegand 26bit or 34bit adjustable |
|
Power/Current |
• Operating Voltage 7-13V DC / Current Draw < 80mA |
|
LED |
• Pulsing White Standby light • Pulsing |
|
Operating Temperature |
• -10°C to +65°C |
|
Operating Humidity |
• 10% to 90% relative humidity • non-condensing |
|
Audio |
• Beep |
|
Index Protection |
• IP65 |
| Dimensions | • ProID10: 80.5 × 44 × 15mm. • ProID20/30: 90 × 90 × 16mm. • ProID40: 116 × 75 × 15mm. |
|
