| Capacity | Fingerprint: 20,000 |
| Card: 10,000 | |
| Transaction: 100,000 | |
| Communication | TCP/IP |
| RS485 (For Slave Reader), Wiegand Input / Output, Security Relay Box | |
| Access Control Interface | Lock Relay Output, Alarm Output / Auxiliary Input |
| Exit Button / Door Sensor, Doorbell Output | |
| Hardware | 1.2GHz High Speed CPU |
| Memory 128MB RAM / 256MB Flash | |
| BioID Fingerprint Sensor, 2.4 Inches TFT-LCD Screen | |
| 125KHz EM Reader / Mifare (Optional), Hi-Fi Voice & Indicator | |
| Anti-dismantle Alarm, Touch Keypad | |
| Standard Functions | Access Levels / Groups / Holidays |
| DST / Bell Schedule | |
| Duress Mode, Anti-Passback, Record Query | |
| Custom Wallpaper & Screen Saver | |
| Special Functions | Multiple Verification Modes, ZK Encrypted Card (Optional) |
| Fingerprint Card (Optional) | |
| Compatibility | Wiegand Slave Reader, RS485 FP Slave Reader |
| ZKBioSecurity Software | |
| Additional Info | Working Temperature: -10 °C ~ 50 °C |
| Dimensions: 202.30x96.80x35.00mm. | |
| Fingerprint Algorithm ZKFinger v10.0 | |
| Fingerprint: FAR≤0.0001% FRR≤0.01% | |
| Package Includes 12V 3A Power Supply | |
| Power | Operating Voltage 12V DC, Current Draw < 500mA |
