| Category | Specification |
|---|---|
| Mechanical Dimensions | 343.2 x 181.2 x 60.2 mm (13.5 x 7.1 x 2.4") |
| Weight | 633 g (1.4 lb) |
| Networking Interface | (2) GbE RJ45 ports |
| Management Interface | Ethernet |
| Power Method | PoE |
| Power Supply | Gigabit PoE adapter 48V DC, 0.5A* |
| Max. Power Consumption | 9W |
| Max. TX Power (2.4 GHz) | 22 dBm |
| Max. TX Power (5 GHz) | 22 dBm |
| Max. TX Power (6 GHz) | – |
| MIMO (2.4 GHz) | 3 x 3 (DL MU-MIMO) |
| MIMO (5 GHz) | 3 x 3 (DL MU-MIMO) |
| MIMO (6 GHz) | – |
| Max. Data Rate (2.4 GHz) | 450 Mbps (BW40) |
| Max. Data Rate (5 GHz) | 1.3 Gbps (BW80) |
| Max. Data Rate (6 GHz) | – |
| Antenna Gain (2.4 GHz) | 8 dBi |
| Antenna Gain (5 GHz) | 8 dBi |
| Antenna Gain (6 GHz) | – |
| Button | Factory reset |
| Mounting | Wall, pole (Included) |
| Ambient Operating Temp. | -40 to 70°C (-40 to 158°F) |
| Ambient Operating Humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC |
| WiFi Standards | 802.11a/b/g/n/ac |
| Wireless Security | WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES) |
| VLAN | 802.1Q |
| BSSID | Up to 4 per radio |
| Advanced QoS | Per-user rate limiting |
| Guest Traffic Isolation | Supported |
| Power Save | Supported |
| WMM | Voice, video, best effort, and background |
| Concurrent Clients | 250+ |
| Supported Data Rates (802.11a) | 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| Supported Data Rates (802.11b) | 1, 2, 5.5, 11 Mbps |
| Supported Data Rates (802.11g) | 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| Supported Data Rates (802.11n) | 6.5 Mbps to 450 Mbps (MCS0 - MCS23, HT 20/40) |
| Supported Data Rates (802.11ac) | 6.5 Mbps to 1.3 Gbps (MCS0 - MCS9 NSS1/2/3, VHT 20/40/80) |
