| Feature | Specification |
|---|---|
| CPU | Dual core 1.7 GHz Hardware Acceleration Engine Layer 4 / Layer 7 |
| Memory | 512 MB DDR3 |
| Antenna Type | 4×4 MIMO Omni-directional high-gain dipole (2.4GHz / 5GHz) |
| LAN Port | Gigabit (RJ-45) x 4, Gigabit (RJ-45) x 3 (Dual WAN) |
| WAN Port | Gigabit (RJ-45) x 1, Gigabit (RJ-45) x 2 (Dual WAN) |
| External Ports | USB 3.0 x 1 (5V, 0.9A power output), USB 2.0 x 1 (5V, 0.5A power output), SD card reader x 1 (SDXC, SDHC) |
| Wireless Standard | IEEE 802.11ac, IEEE 802.11a/b/g/n/ac |
| Data Rate | 5GHz: 1.73Gbps, 2.4GHz: 800Mbps |
| Wi-Fi Features | Simultaneous dual-band Wi-Fi, MU-MIMO, 2×2 160 MHz |
| Wi-Fi Encryption | WEP, WPA/WPA2-Personal, WPA/WPA2-Enterprise, WPA2/WPA3-Personal, WPA3-Personal/Enterprise, OWE |
| Button and Switch | WPS, USB/SD eject, Power, Reset, Wi-Fi On/Off |
| Size | 77 mm x 280 mm x 169 mm |
| Weight | 0.7 kg |
| Operating Temperature | 5°C to 40°C (40°F to 104°F) |
| Storage Temperature | -20°C to 60°C (-5°F to 140°F) |
| Relative Humidity | 5% to 95% RH |
| Certification | FCC, UKCA, CE, BSMI, VCCI, RCM, KC, iDA, TELEC, JATE |
| Wi-Fi Certification | CE, UKCA, FCC, NCC, RCM, iDA, TELEC, KC |
| Warranty | 2 Years |
| AC Input Power | 100 V to 240 V AC |
| Power Frequency | 50/60 Hz, Single Phase |
| Power Consumption | 10.80 W (Access), 7.94 W (Idle) |
| Environment | RoHS Compliant |
| Packaging Content | Main Unit, Antenna x 4, AC Power Adapter, RJ-45 LAN Cable, Quick Installation Guide |
