901-3050-CN00 Specification |
|
| Number of APs supported | Up to 50 |
| Power | 220 watt internal power supply
100–250V AC Universal, IEC 320 connector |
| Physical size | 35.52cm(L), 43.18cm(W), 4.39cm(H) |
| Ethernet ports | 2 ports, auto MDX, auto-sensing 10/100/1000 Mbps, RJ-45 |
| Led display | Power/Status |
| Environmental conditions | Operating Temperature: 41°F (5°C)–104°F (40°C)
Operating humidity: 15%–95% non-condensing |
| Configuration | Web user interface, CLI, FlexMaster |
| Statistics | LAN, wireless and associated stations (available via UI) |
| Auto ap software updates | Supported |
| Captive portal | Supported |
| Guest accounts | Supported |
| VLAN support | 802.1Q (per BSSID), dynamic VLAN |
| DHCP server | Supported |
| Ap discovery & control | Layer-2 or Layer-3 |
| Wlans (BSSIDS) | Up to 32 |
| Radius accounting | Supported |
| Access lists (ACLS) | Layer-2 (MAC address based ACL)
Layer-3 (IP address based ACL) L2 client isolation |
| Wireless intrusion detection (WIDS) | Rogue AP detection
DoS attack prevention Password guessing protection Rate limiting |
| Wireless security | WEP, WPA-TKIP, WPA2-AES, 802.11i |
| Authentication | 802.1X, local database
External AAA servers: ActiveDirectory, RADIUS, LDAP |
| Local authentication | 10,000 user entries |
| VoIP tunneling | Supported |
| 802.11e | Supported |
| Software queues | Per traffic type, per client |
| Auto-classification | Heuristics |
| Rate limiting | Supported |
| Managed aps | Up to 500 |
| Concurrent stations | Up to 10,000 |
