Mikrotik RB1100Dx4 Specifications |
|
| Model | Mikrotik RB1100Dx4 Dude Edition |
| CPU | Annapurna Alpine AL21400 |
| CPU Cores | 4 x Cortex A15 |
| CPU Clock Speed | 1.4GHz each core |
| Max Throughput | Up to 7.5Gbps |
| RAM | 1GB DDR3 |
| Storage | 128MB NAND |
| Ethernet Ports | 13 x Gigabit Ethernet |
| Serial Port | 1 x DB9 RS232 |
| Power Supply | Dual redundant power supplies |
| Power Consumption | Maximum 25W |
| Operating System | RouterOS Level 6 license |
| Dimensions | 444mm x 148mm x 47mm |
| Operating Temperature | -40°C to 70°C |
| Fanless | Yes |
| Mounting | 1U Rackmount |
| USB Ports | 1 x USB 3.0 |
| Switch Chip | 2 x Marvell 88E6171 |
| PCIe Slots | 1 x PCIe Slot |
| LED Indicators | Yes |
