| Specifications |
| Type |
Fixed |
| Topology |
Ethernet (10/100BaseTX) |
| Maximum Port density |
24 10/100 ports |
| Uplinks |
n/a |
| Modular/Expansion Slots |
n/a |
| Architecture |
Layer 2 Switching (basic connectivity), Voice Enabled |
| Form Factor |
Fixed, Rack Mountable, Standalone/Clustering |
| Dimensions |
1.73 x 17.5 x 9.3 in. |
| DRAM |
64 MB |
| Features |
| Specialized Service Modules |
n/a |
| High Availability/Resilliency |
PVST, Broadcast Suppression, Unicast Suppression, Mulitcast Suppression, Spanning Tree, Portfast, Uplink Fast, Backbone Fast, 802.1s, 802.1w |
| Management |
| Management features |
SPAN, CiscoView, Cisco Discover Protocol (CDP), Virtual Trunking Protocol (VTP), Telnet Client, BOOTP, TFTP, CiscoWorks, CWSI, RMON, SNMP, Clustering, Web-Based Management |
| Scalability |
| WAN Interface Support |
n/a |
| Throughput |
3.6 Mpps |
| Backplane Capacity |
16 Gbps |
| Number of VLANs |
64 |
